ARM130.705
Steel Wall Mounted Module
With Bellow
The Steel Wall-Mounted Module - With Bellows helps fixing the operator arms horizontally which are positioned on vertical surfaces. This product with its cast steel body gives reliability for heavy loads and long-distance arm configurations. It allows a mobility of 90° to the right and left.
| Net Weight | 9,5kg. |
| Color | RAL 7035 (Bellow RAL 7016) |
| Amount in package | 1 |
| Package Dimensions | 240x210x240mm |
| Material | Casting Steel |
| Movement | Right 90°, Left 90° |
